Model KM-80C-HC
Hoshizaki
Hoshizaki
Hoshizaki Crescent Ice Maker KM-80C-HC – Self-Contained, Air-cooled, 75 kg/24h
The Hoshizaki KM-80C-HC makes 75 kg of crescent ice a day (self-contained, air-cooled, 34 kg bin). Data, manuals and marine quotation.
| Manufacturer | Hoshizaki |
|---|---|
| Model | KM-80C-HC |
| Product type | Crescent Ice Maker |
| Series | KM series |
| Configuration | Self-Contained |
Hoshizaki Crescent Ice Maker KM-80C-HC Overview
The KM-80C-HC makes up to 75 kg of crescent ice a day and keeps 34 kg of it in its own bin, so it only needs power, water and a drain to start working. Averaged out, the machine turns out about 3.1 kg an hour. An empty 34 kg bin fills in roughly 11 hours at that rate.
Technical details
It measures 605 x 712 x 838 mm (W x D x H) before legs (add 144-167mm) and weighs 50 kg empty. Electrically it needs single-phase 220-240 V 50 Hz, drawing 0.314 kW, within ±6%, on a 5 A breaker. At 32 °C room temperature it releases 0.82 kW of heat. It uses about 430 liters of water a day, or roughly 5.7 liters for every kilo of ice. Inside the KM-80C-HC is a 147 g R290 charge, and R290 is propane rated A3 for flammability. Functions on the KM-80C-HC include automated cleaning.
Installation notes
The KM-80C-HC is rated for rooms at 7 to 38 °C, with feed water between 7 and 32 °C at 0.7 to 8 bar. Expect roughly 0.82 kW of extra heat in the room from this air-cooled unit. Hoshizaki matches the KM-80C-HC with the 4HC-H single filter system. Before quoting we check the board voltage and frequency, the water connection and the fixing on board, since the figures above are for the standard KM-80C-HC.
Key features of the KM-80C-HC
- 75 kg of crescent ice per 24 hours
- 34 kg built-in storage bin
- Air-cooled condenser
- R290 refrigerant
- Exterior: Stainless steel AISI 441, Galvanized steel (Rear), Plastic (Louver)
- Automated cleaning
- Accessories included: Legs, Scoop
KM-80C-HC technical specifications
| Manufacturer | Hoshizaki |
|---|---|
| Model | KM-80C-HC |
| Product type | Crescent Ice Maker |
| Series | KM series |
| Configuration | Self-Contained |
| Manufacturer item number | F160-C141 |
| Country of origin | China |
| Accessories included | Legs, Scoop |
| Compatible water filters | 4HC-H Single Water Filter, 4HC Replacement Cartridge |
| Width | 605 mm |
| Width (packed) | 700 mm |
| Depth | 712 mm |
| Depth (packed) | 805 mm |
| Height | 838 mm |
| Height (packed) | 996 mm |
| Volume (packed) | 0.561 m³ |
| Legs | For legs add 144-167mm |
| Electrical consumption | 0.314 kW |
| Ambient temperature (maximum) | 38 °C |
| Ambient temperature (minimum) | 7 °C |
| Voltage tolerance | ±6% |
| Water supply pressure (maximum) | 0.8MPa (8 bar) |
| Water supply pressure (minimum) | 0.07MPa (0.7 bar) |
| Water supply temperature (maximum) | 32 °C |
| Water supply temperature (minimum) | 7 °C |
| Functions | Automated cleaning |
| Electrical circuit breaker protection | 5 A |
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear), Plastic (Louver) |
| Gross weight | 63 kg |
| Net weight | 50 kg |
| Heat rejection (AT 32 °C, WT 21 °C) | 0.82 kW |
| Power supply | 1/220 - 240V/50Hz |
| Storage bin capacity | 34 kg |
| Cooling system | Air Cooled |
| Ice type | Crescent Edge |
| Ice production (kg/24h) | 75 kg |
| Water consumption (m³/24h) | 0.43 m³ |
| CO2 equivalent | 0.51 kg |
| GWP | 3 GWP |
| Refrigerant charge | 147 g |
| Refrigerant type | R290 |
Also listed under
Questions about the KM-80C-HC
What is the daily output of the Hoshizaki KM-80C-HC?
Up to 75 kg of crescent ice in 24 hours, about 3.1 kg an hour. Real output drops as room and water temperatures rise.
Is the KM-80C-HC air-cooled or water-cooled?
It is air-cooled.
What water supply does the KM-80C-HC need?
Water at 7 to 32 °C and 0.7 to 8 bar, with the 4HC-H single filter system.
Where the KM-80C-HC is used
Hoshizaki, manufacturer of the KM-80C-HC
Hoshizaki: Japanese maker of commercial ice machines, supplied through Hoshizaki Europe with cube, crescent, flake, nugget, cylinder and ball ice makers, ice and water dispensers and sushi display cases. Configured to order — tell us the vessel and the supply voltage and frequency, and we will quote the correct build.
All Hoshizaki equipmentManuals and documents for the KM-80C-HC
Documents are published by the manufacturer for the standard model. We confirm the build, supply and installation details for your vessel with the quotation.
