Model CM-50KE-HC
Hoshizaki
Hoshizaki
Hoshizaki Cubelet Ice Maker CM-50KE-HC – Self-Contained, Air-cooled, 55 kg/24h
55 kg/24h cubelet ice from the Hoshizaki CM-50KE-HC, a self-contained air-cooled unit with a 18 kg bin. Full specs and manuals.
| Manufacturer | Hoshizaki |
|---|---|
| Model | CM-50KE-HC |
| Product type | Cubelet Ice Maker |
| Series | CM series |
| Configuration | Self-Contained |
Hoshizaki Cubelet Ice Maker CM-50KE-HC Overview
The CM-50KE-HC makes up to 55 kg of cubelet ice a day and keeps 18 kg of it in its own bin, so it only needs power, water and a drain to start working. Spread over a day, it is about 2.3 kg per hour. At that rate the 18 kg bin takes around 7.9 hours to rebuild after a busy service.
Technical details
Footprint is 498 x 570 mm with a height of 697 mm; net weight is 49 kg. It draws 0.27 kW from a single-phase 220-240 V 50 Hz supply, within ±6%, on a 6 A breaker. Heat released into the room is 0.45 kW at 32 °C ambient. Daily water use is 55 liters, or roughly 1 liters for every kilo of ice. The CM-50KE-HC runs on 50 g of R290, which is propane (safety class A3), so the charge belongs on the installation paperwork.
Where the CM-50KE-HC fits
Check two things on board before the CM-50KE-HC goes in: room temperature (5 to 40 °C allowed) and water pressure (0.5 to 8 bar, water 5 to 35 °C). Expect roughly 0.45 kW of extra heat in the room from this air-cooled unit. For water treatment, fit the 4HC-H single filter ahead of the CM-50KE-HC. We quote the CM-50KE-HC against your vessel (supply voltage and frequency, water line, fixing), working from Hoshizaki's data for the standard model.
Key features of the CM-50KE-HC
- 55 kg of cubelet ice per 24 hours
- 18 kg built-in storage bin
- Air-cooled condenser
- R290 refrigerant
- Exterior: Stainless steel AISI 441, Galvanized steel (Rear)
- Accessories included: Installation kit, Scoop
CM-50KE-HC technical specifications
| Manufacturer | Hoshizaki |
|---|---|
| Model | CM-50KE-HC |
| Product type | Cubelet Ice Maker |
| Series | CM series |
| Configuration | Self-Contained |
| Manufacturer item number | F161-C103 |
| Country of origin | UK |
| Accessories included | Installation kit, Scoop |
| Compatible water filters | 4HC-H Single Water Filter, 4HC Replacement Cartridge |
| Width | 498 mm |
| Width (packed) | 595 mm |
| Depth | 570 mm |
| Depth (packed) | 680 mm |
| Height | 697 mm |
| Height (packed) | 873 mm |
| Volume (packed) | 0.3532 m³ |
| Electrical consumption | 0.27 kW |
| Energy consumption | 0.27 kWh |
| Ambient temperature (maximum) | 40 °C |
| Ambient temperature (minimum) | 5 °C |
| Voltage tolerance | ±6% |
| Water supply pressure (maximum) | 0.8MPa (8 bar) |
| Water supply pressure (minimum) | 0.05MPa (0.5 bar) |
| Water supply temperature (maximum) | 35 °C |
| Water supply temperature (minimum) | 5 °C |
| Electrical circuit breaker protection | 6 A |
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Gross weight | 58 kg |
| Net weight | 49 kg |
| Heat rejection (AT 32 °C, WT 21 °C) | 0.45 kW |
| Power supply | 1/220 - 240V/50Hz |
| Storage bin capacity | 18 kg |
| Volume, gross | 0.353 l |
| Cooling system | Air Cooled |
| Ice type | Cubelet |
| Ice production (kg/24h) | 55 kg |
| Water consumption (m³/24h) | 0.055 m³ |
| CO2 equivalent | 0.15 kg |
| GWP | 3 GWP |
| Refrigerant charge | 50 g |
| Refrigerant type | R290 |
Also listed under
Questions about the CM-50KE-HC
How much ice does the CM-50KE-HC make per day?
Up to 55 kg of cubelet ice in 24 hours, about 2.3 kg an hour. Real output drops as room and water temperatures rise.
Is the CM-50KE-HC air-cooled or water-cooled?
It is air-cooled.
What water supply does the CM-50KE-HC need?
Water at 5 to 35 °C and 0.5 to 8 bar, with the 4HC-H single filter system.
Where the CM-50KE-HC is used
Hoshizaki, manufacturer of the CM-50KE-HC
Hoshizaki: Japanese maker of commercial ice machines, supplied through Hoshizaki Europe with cube, crescent, flake, nugget, cylinder and ball ice makers, ice and water dispensers and sushi display cases. Configured to order — tell us the vessel and the supply voltage and frequency, and we will quote the correct build.
All Hoshizaki equipmentManuals and documents for the CM-50KE-HC
Documents are published by the manufacturer for the standard model. We confirm the build, supply and installation details for your vessel with the quotation.
