Hoshizaki Flake Ice Maker FM-60KE-HC – Self-Contained, Air-cooled, 65 kg/24h
Hoshizaki FM-60KE-HC: self-contained air-cooled flake ice maker, 65 kg a day with a 18 kg bin. Specs, manuals and quotes for ships and yachts.
| Manufacturer | Hoshizaki |
|---|---|
| Model | FM-60KE-HC |
| Product type | Flake Ice Maker |
| Series | FM series |
| Configuration | Self-Contained |
Hoshizaki Flake Ice Maker FM-60KE-HC Overview
The FM-60KE-HC makes up to 65 kg of flake ice a day and keeps 18 kg of it in its own bin, so it only needs power, water and a drain to start working. That works out to roughly 2.7 kg an hour. An empty 18 kg bin fills in roughly 6.6 hours at that rate.
Technical details
The cabinet is 498 mm wide, 570 mm deep and 697 mm tall, and weighs 49 kg. Power draw is 0.27 kW on single-phase 220-240 V 50 Hz, within ±6%, on a 6 A breaker. Plan for 0.45 kW of heat into the space at 32 °C. Water consumption comes to 65 liters per 24 hours, or roughly 1 liters for every kilo of ice. Refrigerant is 50 g of flammable R290 (A3), a figure the yard or class surveyor will ask for.
Fitting it on a vessel
Check two things on board before the FM-60KE-HC goes in: room temperature (5 to 40 °C allowed) and water pressure (0.5 to 8 bar, water 5 to 35 °C). Being air-cooled, the FM-60KE-HC warms the space it stands in by about 0.45 kW; in a small pantry that is worth planning for. The matching water filter for 65 kg a day is the 4HC-H single system. Before quoting we check the board voltage and frequency, the water connection and the fixing on board, since the figures above are for the standard FM-60KE-HC.
Key features of the FM-60KE-HC
- 65 kg of flake ice per 24 hours
- 18 kg built-in storage bin
- Air-cooled condenser
- R290 refrigerant
- Exterior: Stainless steel AISI 441, Galvanized steel (Rear)
- Accessories included: Installation kit, Scoop
FM-60KE-HC technical specifications
| Manufacturer | Hoshizaki |
|---|---|
| Model | FM-60KE-HC |
| Product type | Flake Ice Maker |
| Series | FM series |
| Configuration | Self-Contained |
| Manufacturer item number | F161 |
| Country of origin | UK |
| Accessories included | Installation kit, Scoop |
| Compatible water filters | 4HC-H Single Water Filter, 4HC Replacement Cartridge |
| Width | 498 mm |
| Width (packed) | 595 mm |
| Depth | 570 mm |
| Depth (packed) | 680 mm |
| Height | 697 mm |
| Height (packed) | 873 mm |
| Volume (packed) | 0.3532 m³ |
| Electrical consumption | 0.27 kW |
| Energy consumption | 0.27 kWh |
| Ambient temperature (maximum) | 40 °C |
| Ambient temperature (minimum) | 5 °C |
| Voltage tolerance | ±6% |
| Water supply pressure (maximum) | 0.8MPa (8 bar) |
| Water supply pressure (minimum) | 0.05MPa (0.5 bar) |
| Water supply temperature (maximum) | 35 °C |
| Water supply temperature (minimum) | 5 °C |
| Electrical circuit breaker protection | 6 A |
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Gross weight | 58 kg |
| Net weight | 49 kg |
| Heat rejection (AT 32 °C, WT 21 °C) | 0.45 kW |
| Power supply | 1/220 - 240V/50Hz |
| Storage bin capacity | 18 kg |
| Volume, gross | 0.353 l |
| Cooling system | Air Cooled |
| Ice type | Flake |
| Ice production (kg/24h) | 65 kg |
| Water consumption (m³/24h) | 0.065 m³ |
| CO2 equivalent | 0.15 kg |
| GWP | 3 GWP |
| Refrigerant charge | 50 g |
| Refrigerant type | R290 |
Also listed under
Questions about the FM-60KE-HC
How much ice does the FM-60KE-HC make per day?
Up to 65 kg of flake ice in 24 hours, about 2.7 kg an hour. Real output drops as room and water temperatures rise.
How is the FM-60KE-HC cooled?
It is air-cooled.
What water supply does the FM-60KE-HC need?
Water at 5 to 35 °C and 0.5 to 8 bar, with the 4HC-H single filter system.
Where the FM-60KE-HC is used
Hoshizaki, manufacturer of the FM-60KE-HC
Hoshizaki: Japanese maker of commercial ice machines, supplied through Hoshizaki Europe with cube, crescent, flake, nugget, cylinder and ball ice makers, ice and water dispensers and sushi display cases. Configured to order — tell us the vessel and the supply voltage and frequency, and we will quote the correct build.
All Hoshizaki equipmentManuals and documents for the FM-60KE-HC
- Spec sheet
- Instruction manual (1)
- Instruction manual (2)
- Installation manual
- Declaration of conformity
Documents are published by the manufacturer for the standard model. We confirm the build, supply and installation details for your vessel with the quotation.
