Hoshizaki Nugget Ice Maker FM-120KE-HCN – Self-Contained, Air-cooled, 110 kg/24h
Hoshizaki FM-120KE-HCN: self-contained air-cooled nugget ice maker, 110 kg a day with a 32 kg bin. Specs, manuals and quotes for ships and yachts.
| Manufacturer | Hoshizaki |
|---|---|
| Model | FM-120KE-HCN |
| Product type | Nugget Ice Maker |
| Series | FM series |
| Configuration | Self-Contained |
Hoshizaki Nugget Ice Maker FM-120KE-HCN Overview
Hoshizaki rates the FM-120KE-HCN at 110 kg of nugget ice per day. The ice drops into a 32 kg bin inside the same air-cooled cabinet. Spread over a day, it is about 4.6 kg per hour. From empty, its 32 kg bin takes about 7 hours to fill.
Power, water and size
It measures 640 x 600 x 711 mm (W x D x H) before legs (add 87-122mm) and weighs 66 kg empty. Electrically it needs single-phase 220-240 V 50 Hz, drawing 0.355 kW, within ±6%, on a 6 A breaker. Heat released into the room is 0.66 kW at 32 °C ambient. Daily water use is 110 liters, or roughly 1 liters for every kilo of ice. Refrigerant is 100 g of flammable R290 (A3), a figure the yard or class surveyor will ask for.
Fitting it on a vessel
The FM-120KE-HCN is rated for rooms at 5 to 40 °C, with feed water between 5 and 35 °C at 0.5 to 8 bar. Air-cooled, it puts its 0.66 kW of heat straight into the room, so a closed pantry needs some ventilation. Hoshizaki matches the FM-120KE-HCN with the 4HC-H single filter system. We quote the FM-120KE-HCN against your vessel (supply voltage and frequency, water line, fixing), working from Hoshizaki's data for the standard model.
Key features of the FM-120KE-HCN
- 110 kg of nugget ice per 24 hours
- 32 kg built-in storage bin
- Air-cooled condenser
- R290 refrigerant
- Exterior: Stainless steel AISI 441, Galvanized steel (Rear)
- Accessories included: Installation kit, Scoop
FM-120KE-HCN technical specifications
| Manufacturer | Hoshizaki |
|---|---|
| Model | FM-120KE-HCN |
| Product type | Nugget Ice Maker |
| Series | FM series |
| Configuration | Self-Contained |
| Manufacturer item number | F115-C106 |
| Country of origin | UK |
| Accessories included | Installation kit, Scoop |
| Compatible water filters | 4HC-H Single Water Filter, 4HC Replacement Cartridge |
| Width | 640 mm |
| Width (packed) | 746 mm |
| Depth | 600 mm |
| Depth (packed) | 706 mm |
| Height | 711 mm |
| Height (packed) | 887 mm |
| Volume (packed) | 0.4672 m³ |
| Legs | For legs add 87-122mm |
| Electrical consumption | 0.355 kW |
| Ambient temperature (maximum) | 40 °C |
| Ambient temperature (minimum) | 5 °C |
| Voltage tolerance | ±6% |
| Water supply pressure (maximum) | 0.8MPa (8 bar) |
| Water supply pressure (minimum) | 0.05MPa (0.5 bar) |
| Water supply temperature (maximum) | 35 °C |
| Water supply temperature (minimum) | 5 °C |
| Electrical circuit breaker protection | 6 A |
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Gross weight | 76 kg |
| Net weight | 66 kg |
| Heat rejection (AT 32 °C, WT 21 °C) | 0.655 kW |
| Power supply | 1/220 - 240V/50Hz |
| Storage bin capacity | 32 kg |
| Cooling system | Air Cooled |
| Ice type | Nugget |
| Ice production (kg/24h) | 110 kg |
| Water consumption (m³/24h) | 0.11 m³ |
| CO2 equivalent | 0.3 kg |
| GWP | 3 GWP |
| Refrigerant charge | 100 g |
| Refrigerant type | R290 |
Also listed under
Questions about the FM-120KE-HCN
How much ice does the FM-120KE-HCN make per day?
Up to 110 kg of nugget ice in 24 hours, about 4.6 kg an hour. Real output drops as room and water temperatures rise.
Is the FM-120KE-HCN air-cooled or water-cooled?
It is air-cooled.
What water supply does the FM-120KE-HCN need?
Water at 5 to 35 °C and 0.5 to 8 bar, with the 4HC-H single filter system.
Where the FM-120KE-HCN is used
Hoshizaki, manufacturer of the FM-120KE-HCN
Hoshizaki: Japanese maker of commercial ice machines, supplied through Hoshizaki Europe with cube, crescent, flake, nugget, cylinder and ball ice makers, ice and water dispensers and sushi display cases. Configured to order — tell us the vessel and the supply voltage and frequency, and we will quote the correct build.
All Hoshizaki equipmentManuals and documents for the FM-120KE-HCN
- Spec sheet
- Instruction manual (1)
- Instruction manual (2)
- Installation manual
- Declaration of conformity
Documents are published by the manufacturer for the standard model. We confirm the build, supply and installation details for your vessel with the quotation.
