Ship Tumble Dryers

Tumble Dryers on Ships

A ship's laundry washes crew bedding, towels and workwear for the length of a rotation, and larger vessels add accommodation linen. Of the 42 marine tumble dryers in the catalogue, 36 are listed here for ships. A vented dryer needs a DN 100 exhaust duct; a heat-pump dryer needs none, only a condensate drain, which removes a hull or superstructure penetration at the cost of a longer cycle.

What this selection includes

This page lists 36 products from Miele (36), limited to Air vented dryers. By series: Benchmark (28) and Little Giants (8). Across the list you will find rated power from 6.4 kW to 44.1 kW on the 35 models that publish it and load sizes up to 8 kg, 13 to 20 kg, 21 to 30 kg and over 30 kg.

By load size, up to 8 kg (8), 13 to 20 kg (1), 21 to 30 kg (1) and over 30 kg (1). By connected load, up to 5 kw (4), 5 to 10 kw (7), 10 to 20 kw (11) and 20 to 40 kw (14).

A few of the models listed here: Miele Tumble Dryer PDR 922 (23.5 kW), Miele Tumble Dryer PDR 928 (33 kW), Miele Tumble Dryer PDR 944 (44.1 kW) and Miele Tumble Dryer PDR 507 (7 kg, 5.4 kW).

Specifying tumble dryers for ships

• Supply: builds are listed at 208 V, 230 V, 240 V, 400 V, 440 V or 480 V, 36 of them with 60 Hz operation, and the order follows the vessel's own supply rather than the catalogue default.
• Power: 6.4 kW at the low end, 44.1 kW at the high end where published; the total laundry load is what the switchboard sees.
• Dryer type: a vented dryer needs a DN 100 exhaust duct, a heat-pump dryer only a condensate drain.
• Number of machines: several smaller machines for a crew laundry, fewer large ones for a hotel-style laundry.

See all marine tumble dryers in the catalogue, the ship galley equipment page, and the ship galley equipment guide.
